Real-time display of dispense type/temperature/water quality/flow rate/volume.
User authority management and password protection.
Three dispensing modes: quick, scheduled, and fixed-quality/quantity.
Function to prevent RO product water from entering storage system during initial RO membrane operation (within 60 seconds).
Unique pre-filter flushing function for better water quality.
Real-time monitoring and usage recording of feed water/RO product/pre-ultrapurification column product/RO pure water/UP ultrapure water flow rates.
Real-time water monitoring and lifespan determination of pre-treatment column/RO membrane/pre-ultrapurification column/ultrapurification column.
Efficient bacteria regeneration inhibition through dispensing cycle, standby cycle and multi-channel cycle technologies.
UV sterilizer integrated in pure water piping.
Multiple alarm functions: low water protection, high/low water level protection, consumable identification, water quality non-compliance, consumable life expiration, fault alarm, water leakage protection (optional).
Automatic recording and storage of all fault/dispensing/consumable replacement records; complete data downloadable via USB; real-time printing (optional) for full traceability.
| Product Model | UZGPL-I | UPZGL-II | UPZGL-III | Remarks |
| Feed Water Requirements | TDS < 200 ppm, Water Pressure 0.10–0.40 MPa, Water Temperature 5–45°C | Consumable life relates to feed water quality | ||
| Process Technology | Single-stage RO + Ultrapurification | Double-stage RO + Ultrapurification | Double-stage RO + EDI + Ultrapurification | |
| Water Production Capacity | 30/60/90/120 (L/h) | 20/40/60 (L/h) | 30/50 (L/h) | |
| Water Dispensing Rate | 2.0 L/min | |||
| RO Water Quality | Conductivity ≤ Feed Water Conductivity × 2% | Conductivity Range: 1–5 μS/cm | real-time monitoring | |
| UP Water Quality | 18.2 MΩ·cm @25°C (real-time monitoring); Microparticles ≤ 1/ml; Microorganisms ≤ 1 CFU/ml; Heavy metal ions ≤ 0.1 ppb. | |||
| / | TOC≤5ppb | |||
| Dual-Wavelength UV Digester | / | 185/254nm | ||
| Mercury-free UV Sterilizer | Wavelength 270nm | / | ULUPURE patented technology | |
| Unit Dimensions | 500W × 650D × 1205H (mm) | W: Front Width / D: Side Depth / H: Height | ||
| Unit Weight | Approx. 85–115 kg | |||
| Power Supply | AC220V ~ 50 Hz (Power: 170–605 W) | |||
| Storage Tank | 30 L model: standard 40 L constant-pressure tank;60/90 L model: standard 80 L constant-pressure tank;120 L model: standard 100 L constant-pressure tank. | 100 L PE pure water tank | ||
| Applications | AAS, AES, IC, HPLC, ICP/MS, VOC, IVF, PCR, LC/GC, amino acid analysis, protein purification, electrophoresis/gel analysis, toxicology analysis, animal/plant cell culture, molecular biology, genetic research, in vitro fertilization (IVF) | |||
Ordering Notes
1. The water production capacity stated for this product refers to the rated output of the RO membrane at a water temperature of 25°C. For every 1°C decrease in water temperature, the RO membrane’s production decreases by approximately 3%. When the water temperature falls below 5°C, the RO membrane will cease water production. Users must consider the seasonal drop in water temperature in their local region when selecting and ordering the system.
2. The TOC level of the produced water is related to the TOC value of the feed water and the system configuration.
3. For areas with poor feed water quality (TDS ≥ 200 ppm), it is recommended to equip a fully automatic water softener, which can effectively reduce consumable consumption in subsequent system components.
4. With an optional ultrafiltration membrane (3000 Dalton, for applications such as animal cell experiments), endotoxin levels can be reduced to below 0.001 EU/ml.
