【Purified Water Equipment】—Youpu Pure Water Machine Equipment Brand Technology

Purified water equipment is used to produce purified water to meet the needs of various industries, primarily in pharmaceuticals, biochemicals, and hospitals. The entire system is constructed entirely of SUS304L or SUS316L stainless steel, and must be equipped with ultraviolet and ozone sterilization devices before the point of use (some countries prohibit the use of ozone, so pasteurization is used instead). The core technology of purified water equipment utilizes the latest processes such as reverse osmosis and EDI, and is specifically designed as a complete high-purity water treatment process to meet the water requirements of pharmaceutical factories and hospitals for purified water production and large-volume infusion production.

Preparation Process Flow: Raw water – Raw water pressurization pump – Multi-media filter – Activated carbon filter – Water softener – Precision filter – First-stage reverse osmosis – pH adjustment – Intermediate water tank – Second-stage reverse osmosis (reverse osmosis membrane surface is positively charged) – Purified water tank – Pure water pump – Ultraviolet sterilizer – Microfiltration filter – Point of use. The purified water equipment mainly adopts advanced reverse osmosis technology, ensuring reliable quality and stable output water. It uses the latest high-quality stainless steel as the material, offering advantages such as corrosion resistance and rust prevention. The purified water equipment in the sterilization supply room mainly consists of multiple water treatment units.

Purified Water Quality Standards

Chemical Indicators: Meets the pharmaceutical purified water requirements of the 2010 edition of the Pharmacopoeia of the People's Republic of China

Purified Water Equipment

Hygienic Tests: Microorganisms 10 CFU/100ml

Endotoxins 0.25 EU/ml

Conductivity ≤2 μS/cm (Resistivity ≥ 0.5 MΩ) *CM)

(1) Automatic control, simple and convenient operation;

(2) The entire set of equipment is made of stainless steel, and the water tank is made of stainless steel pharmaceutical-grade water tank;

(3) Equipped with a water softener to ensure stable operation of the RO and EDI systems due to hardness;

(4) Uses imported Hydranautics ultra-low pressure reverse osmosis, with high desalination rate, long service life, stable operation, and low energy consumption (reduced by 20%);

(5) The reverse osmosis system is fully automatic, and the main components are imported, ensuring high stability and simple and convenient operation;

(6) The EDI system uses a constant pressure regulation system to ensure stable water quality;

(7) Uses genuine original imported membrane stacks, with stable performance, long service life, and has passed special testing.

(8) The EDI system uses imported flow meters to prevent damage to the membrane stack caused by the lack of concentrated water due to blockage of the concentrate channel or other equipment failures;

(9) The EDI system is equipped with ultraviolet sterilization and membrane filters to ensure stable EDI water quality; (10) It has multiple safety functions such as waterless protection and high/low pressure protection; (11) All water tanks use purified water and dedicated water tanks, and are equipped with pressure level gauges, rotary spray cleaning and air breathing devices; (12) It is equipped with ozone sterilization to ensure quality and quantity, and is designed according to optimal configuration.

Application Areas: Purified water equipment is mainly used for production water in medical large-volume infusions, pharmaceutical preparations, biological preparations, genetic engineering, kidney dialysis, etc.
